Gold Cube 3/4" Pipe Thread × 1-1/8" Hose-Barb Fitting – New Style

Replace a lost, damaged, or leaking water fitting on a compatible Gold Cube 3-Stack or 4-Stack system. This new-style Gold Cube fitting uses a 3/4-inch male pipe thread on one end and a 1-1/8-inch hose barb on the other.

The threaded end installs into the Gold Cube’s water inlet, while the barbed end connects to the standard 1-1/8-inch pump hose used with the system.

Designed for Gold Cube 3-Stack and 4-Stack Systems

This fitting is intended for compatible newer Gold Cube 3-Stack and 4-Stack concentrators that use a 3/4-inch threaded inlet.

Gold Cube accessories do not all use the same thread size. The Gold Banker and Nugget Zone commonly use a different 1-inch pipe-thread fitting. Check your existing fitting or equipment inlet before ordering.

Key Features

• Replacement fitting for compatible Gold Cube concentrators

• Fits newer Gold Cube 3-Stack systems

• Fits newer Gold Cube 4-Stack systems

• 3/4-inch male pipe-thread connection

• 1-1/8-inch barbed hose connection

• Connects the pump hose to the Gold Cube

• Lightweight plastic construction

• Simple threaded installation

• Useful replacement or field-spare component

• Genuine Gold Cube-compatible hardware

Product Specifications

• Brand: Gold Cube

• Product type: Threaded hose-barb adapter

• Manufacturer reference SKU: GC-47

• Equipment-side connection: 3/4-inch male pipe thread

• Hose-side connection: 1-1/8-inch hose barb

• Material: Plastic

• Compatible hose inside diameter: 1-1/8 inches

• Compatible equipment: Newer Gold Cube 3-Stack and 4-Stack systems

• Hose included: No

• Hose clamp included: No

• Thread sealant included: No

• Quantity: One fitting

Compatibility Notice

Compatible with:

• Newer Gold Cube 3-Stack concentrators using a 3/4-inch threaded inlet

• Newer Gold Cube 4-Stack concentrators using a 3/4-inch threaded inlet

• Compatible 1-1/8-inch inside-diameter pump hose

Not intended for:

• Gold Cube Gold Banker fittings that require a different thread size

• Gold Cube Nugget Zone fittings that require a different thread size

• Equipment with a 1-inch threaded inlet

• Hoses with an inside diameter other than 1-1/8 inches

If your original fitting is available, compare both thread and hose dimensions before purchasing.

Installation

1. Disconnect the pump and drain the system.

2. Remove the old fitting from the Gold Cube.

3. Clean the threaded opening.

4. Apply a compatible thread sealant if recommended for your system.

5. Start the fitting by hand to prevent cross-threading.

6. Tighten only enough to create a secure seal.

7. Slide the 1-1/8-inch hose over the barbed end.

8. Install an appropriately sized hose clamp when required.

9. Run the pump and inspect the connection for leaks.

Because the fitting is plastic, avoid overtightening it. Excessive force may damage the fitting or the Gold Cube’s threaded inlet.

What’s Included

• One new-style Gold Cube 3/4-inch pipe-thread to 1-1/8-inch hose-barb fitting

Ideal For

• Replacing a cracked Gold Cube fitting

• Replacing a lost water-inlet adapter

• Repairing a leaking hose connection

• Keeping a spare fitting in a prospecting repair kit

• Connecting compatible replacement hose to a Gold Cube

Restore the water connection on your compatible Gold Cube 3-Stack or 4-Stack with this new-style replacement fitting.

This is the new fitting used on the Gold Cube.  It’s 3/4″ pipe thread  goes into the cube and the 1-1/8″ barbed  goes to the hose.
