10″ x 47″ Gold Sluice with Vortex Dream Mat

Process more material while reducing cleanup time with the 10″ x 47″ Gold Sluice with Vortex Dream Mat. This full-length stream sluice combines sturdy 16-gauge aluminum construction with Prospectors Dream’s patented vortex-cell recovery technology for efficient capture of fine gold, flakes and larger placer gold.

The included Vortex Dream Mat creates active exchange within each cell. Lighter material is continuously displaced while heavier gold settles into protected capture zones. This riffle-free recovery system reduces the amount of unwanted material retained in the sluice, resulting in smaller cleanups and fewer concentrates to process.

Its 10-inch-wide channel and approximately 36-inch-long recovery mat provide the capacity needed for serious stream prospecting. The simple hook-style slick-plate clamp securely holds the mat without requiring loose screws or separate clamps.

Key Features

• Regular Vortex Dream Mat: Versatile recovery profile for fine gold, flakes and larger placer gold

• Patented vortex-cell technology: Uses controlled hydraulic action to separate heavy gold from lighter material

• Active material exchange: Continuously clears lighter material while retaining heavier values

• Front-row capture: Gold begins settling as material enters the recovery section

• High-volume design: Ten-inch-wide channel provides excellent material-processing capacity

• Full-length recovery area: Approximately 36 inches of Dream Mat provides extended gold capture

• 16-gauge aluminum construction: Offers a sturdy and durable sluice platform

• Slick-plate mat clamp: Hook-style retention system holds the mat without loose screws or separate clamps

• Reduced concentrates: Captures valuable material without retaining excessive amounts of lighter waste

• Fast cleanup: Remove and rinse the mat without disassembling traditional riffles, expanded metal or miner’s moss

Benefits

• Processes a higher volume of material than many traditional narrow sluices

• Handles a broad range of placer-gold sizes

• Allows suitable material to be fed without extensive classification

• Produces fewer concentrates for faster final processing

• Eliminates complicated traditional riffle assemblies

• Offers quick visual inspection of the recovery cells

• Easy to clean between sampling locations

• Suitable for both beginning and experienced prospectors

• Operates with properly adjusted natural stream flow

• Can be adapted to custom powered or recirculating systems with separately purchased equipment

Ideal For

• Creek and river prospecting

• Placer-gold recovery

• Fine gold, flakes and small nuggets

• Processing sandy and gravel-rich material

• High-volume stream sluicing

• Testing potential pay streaks

• Recreational and serious prospecting

• Remote gold-bearing locations

• Custom power-sluice and recirculating projects

Specifications

• Product type: Gold prospecting stream sluice

• Manufacturer: Prospectors Dream

• Sluice material: 16-gauge aluminum

• Recovery system: Regular Vortex Dream Mat

• Recovery technology: Patented vortex-cell design

• Mat retention: Hook-style slick-plate clamp

• Sluice width: Approximately 10 inches

• Sluice length: Approximately 47 inches

• Mat width: Approximately 10 inches

• Mat length: Approximately 36 inches

• Power requirement: Natural stream flow

• SKU: PD-10X47-SLUICE-VORTEX

• Mat color: May vary

Dimensions

• Sluice box: Approximately 10″ wide × 47″ long

• Vortex Dream Mat: Approximately 10″ wide × 36″ long

• Dimensional note: Sluice and molded-mat lengths may vary slightly

What’s Included

• 10″ × 47″ aluminum sluice box

• Approximately 10″ × 36″ Regular Vortex Dream Mat

• Hook-style slick-plate mat-retention system

Pump, hose, header box, stand, legs, battery and recirculating tub are not included.

Recommended Operation

Place the sluice securely in a suitable section of moving water. Adjust its slope and water flow until the vortex cells are actively exchanging material. The cells should clear lighter sand and gravel while maintaining protected low-pressure zones for gold capture.

Although the Vortex Dream Mat can process unclassified material, remove rocks that are too large for the sluice and break apart clay before feeding. Add material steadily across the width of the sluice and avoid burying the active cells faster than they can exchange lighter material.

Water conditions and material composition vary, so test the sluice with small amounts of material and make gradual adjustments before beginning full production.

Fast Cleanup

Stop feeding material and allow the water to clear lighter material from the mat. Release the slick-plate retention system, carefully remove the Dream Mat and rinse the captured concentrates into a gold pan or suitable cleanup tub.

Because the recovery system does not rely on conventional riffles, expanded metal or miner’s moss, cleanups are fast and require fewer parts to remove.

Important Mat Information

Dream Mat color may vary according to the manufacturer’s current production run. Slight dimensional variations are normal with molded recovery matting and do not affect its intended performance.

Why Choose the 10″ × 47″ Gold Sluice with Vortex Dream Mat?

The 10″ × 47″ Gold Sluice with Vortex Dream Mat delivers the capacity of a full-length stream sluice with the efficiency and simple cleanup of a modern vortex-cell recovery system. Its sturdy aluminum construction, extended recovery area and versatile Vortex Dream Mat make it an excellent choice for prospectors who want to process more material while taking home fewer concentrates.

Process More Material, Reduce Your Concentrates and Recover More Gold with the 10″ × 47″ Gold Sluice with Vortex Dream Mat.

10" X 47" SLUICE BOX W/ REGULAR VORTEX DREAM MAT

THE SIMPLE HOOK SLICK PLATE CLAMP REQUIRES NO SCREWS OR CLAMPS. 16 Ga. ALUIM. CONSTRUCTION IS VERY STURDY.

THIS SLUICE WILL OUTPERFORM A TRADITIONAL 12" WIDE SLUICE IN VOLUME & YOU DO NOT NEED TO CLASSIFY, SHOVEL IT RIGHT IN. REDUCE YOUR CONS, HAVE INSTANT CLEAN OUTS, PROCESS MORE MATERIAL, TAKE HOME MORE GOLD!
